HP ESA-L1500A User Manual

Chapter 7 161
Specifications
Options
Options
Tracking Generator Specifications (Option 1DN
or 1DQ)
(The temperature range for tracking generator specifications is 20˚C to
30˚C.)
Specifications Supplemental Information
Output Frequency Range
50 Ω (Option 1DN) 9 kHz to 1.5 GHz
75 Ω (Option 1DQ) 1 MHz to 1.5 GHz
Specifications Supplemental Information
Residual FM
< 10 MHz ≤100 Hz peak, 20 Hz to
10 kHz BW
≥ 10 MHz ≤100 Hz peak, 20 Hz to
200 kHz BW
Specifications Supplemental Information
Output Power Level
Range
50 Ω (Option 1DN) 0 to −70 dBm
75 Ω (Option 1DQ) +42.76 to −27.24 dBmV
Resolution 0.1 dB
Absolute Accuracy (at 50 MHz
with coupled source
attenuator)
50 Ω (Option 1DN)
Referenced to 0 dBm
± 0.5 dB
75 Ω (Option 1DQ)
Referenced to +42.76 dBmV
± 0.5 dB
