HP Ethernet 10Gb 2-port 530T Adapter User Manual

Specifications 12
Compliance Standard
Other
PCIe 2.1
RoHS 6 of 6
IPv6
CE
Microsoft Windows Hardware Quality Labs
Server Design Guide version 3.0
SNMP
IPv4, TCP and UDP Checksum Offload
IPv4/IPv6 TCP, Large Send Offload
Receive-Side Scaling
Jumbo Frames up to 9000 bytes
Power and environmental specifications
Specification Value
Power
4 W typical, 9 W maximum
10 W typical, 20 W maximum (with PHY)
Temperature
Operating—0° to 55° C (32° to 131° F)
Non-operating—65° to 85° C (-85° to 185° F)
Humidity
Operating—10 to 90% relative humidity, non-condensing
Non-operating—5 to 95% relative humidity, non-condensing

HP Ethernet 10Gb 2-port 530T Adapter Specifications

General

Ports	2
Data Rate	10Gbps
Connector	RJ-45
Form Factor	Plug-in card
Interface	PCI Express 2.0 x8
Product Type	Network adapter
Chipset Manufacturer	Intel
Data Transfer Rate	20 Gb/s (full duplex)
Compatible Slots	PCI Express x8
Operating Systems Supported	Windows, Linux
