Item Description Spare part number
●
Intel Core2 Duo P7350 2.00-GHz processor (3-MB L2 cache)
501520-001
●
Intel Core2 Duo T5900 2.20-GHz processor (2-MB L2 cache)
501522-001
●
Intel Core2 Duo T5800 2.00-GHz processor (2-MB L2 cache)
501521-001
●
Intel Pentium Dual-Core T3400 2.16-GHz processor (1-MB L2 cache)
501523-001
●
Intel Pentium Dual-Core T3200 2.00-GHz processor (1-MB L2 cache)
501519-001
●
Intel Celeron 585 2.16-GHz processor (1-MB L2 cache)
494285-001
●
Intel Celeron 575 2.00-GHz processor (1-MB L2 cache)
494284-001
Processor bracket (not illustrated) 486635-001
(12) Fan/heat sink assembly (includes replacement thermal material) 486636-001
(13) Power connector cable 486637-001
(14) Bluetooth® module (does not include Bluetooth module cable) 483113-001
Bluetooth module cable 486640-001
(15) USB board (does not include USB board cable) 486633-001
USB board cable (includes num lock LED) 486639-001
(16) RJ-11 connector cable 486638-001
(17) Audio board (includes audio board cable) 486634-001
(18) Base enclosures (include rubber feet)
For use only with computer models equipped with a Digital Media Slot and an HDMI port 486625-001
For use only with computer models equipped with a Digital Media Slot, but not an HDMI port 492300-001
For use only with computer models equipped with an HDMI port, but not a Digital Media Slot 492301-001
For use only with computer models not equipped with a Digital Media Slot or an HDMI port 494183-001
Rubber Kit (not illustrated, includes 8 computer feet) 486623-001
(19) Batteries
12-cell, 2.20-Ah, 95-Wh battery 484172-001
6-cell, 2.55-Ah, 55-Wh battery 484171-001
6-cell, 2.20-Ah, 47-Wh battery 485041-001
(20) Hard drives (include hard drive bracket and connector)
For models equipped with AMD processors:
250-GB, 5400-rpm 485036-001
200-GB, 5400-rpm 490829-001
160-GB, 5400-rpm 485035-001
120-GB, 5400-rpm 485034-001
For models equipped with Intel processors:
250-GB, 5400-rpm 485036-002
18 Chapter 3 Illustrated parts catalog
