2. Lift the right side of the cover (2), swing it up and to the left, and remove the cover (3). The memory
module compartment cover is included in the base enclosure.
3. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The edge of the module opposite the slot rises away from the computer.)
4. Remove the memory module (2) by pulling the module away from the slot at an angle.
NOTE: Memory modules are designed with a notch (3) to prevent incorrect installation into the
memory module slot.
Reverse this procedure to install a memory module.
48 Chapter 4 Removal and replacement procedures
