7–8 Maintenance and Service Guide
Screw listing
Phillips PM2.5×6.0 captive screw
Where used: 3 screws that secure the fan/heat sink assembly to the base enclosure (screws are secured by C-clips)
on computer models equipped with graphics subsystems having UMA memory
Where used: 5 screws that secure the fan/heat sink assembly to the base enclosure (screws are secured by C-clips)
on computer models equipped with graphics subsystems having discrete memory
Color Quantity Length Thread Head diameter
Silver 13 6.0 mm 2.5 mm 5.0 mm
