Removal and replacement procedures
Maintenance and Service Guide 4–13
Memory module
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-7).
5. Remove hard drive cover (see “Hard drive” on page 4-10).
Remove the memory module:
1. Spread the retaining tabs 1 away from the memory module. (The edge of the module opposite the slot rises
away from the computer.)
2. Remove the memory module 2 by pulling the module away from the slot at an angle.
✎
Memory modules are designed with a notch 3 to prevent incorrect insertion into the memory module slot.
Reverse this procedure to install a memory module.
Description Spare part number
Memory module, 1-GB, PC2-6400 517843-001
Memory module, 2-GB, PC2-6400 517844-001
