Removal and replacement procedures
Maintenance and Service Guide 4–23
Display assembly
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-7).
5. Disconnect the wireless antenna cables from the wireless module (see “Wireless module” on page 4-14).
6. Remove the keyboard (see “Keyboard” on page 4-17).
7. Remove the switch cover (see “Switch cover” on page 4-20).
Description Spare part number
16-inch High Definition, light-emitting diode display assembly for HP G61 computer models
(includes webcam module and cable, 2 WLAN antenna transceivers and cables, microphone
and cable, and logo)
530981-001
16-inch High Definition, light-emitting diode display assembly for Presario G61 computer models
(includes webcam module and cable, 2 WLAN antenna transceivers and cables, microphone and
cable, and logo)
530977-001
15.6-inch High Definition, light-emitting diode display assembly for Presario CQ61 computer models
(includes microphone and cable, and logo)
530979-001
15.6-inch High Definition, light-emitting diode display assembly for Presario CQ61 computer models
(includes webcam module and cable, 2 WLAN antenna transceivers and cables, microphone and
cable, and logo)
530978-001
15.6-inch High Definition, light-emitting diode display assembly for HP G61 computer models
(includes microphone and cable, and logo)
530983-001
15.6-inch High Definition, light-emitting diode display assembly for HP G61 computer models
(includes webcam module and cable, 2 WLAN antenna transceivers and cables, microphone and
cable, and logo)
530982-001
