Illustrated parts catalog
Maintenance and Service Guide 3–11
Item Description Spare Part Number
(1) Display bezel
For use only with 16-in HP G61 display (includes microphone and webcam) 530478-001
For use only with 15.6-in HP G61 display (includes microphone and webcam) 530992-001
For use only with 15.6-in HP G61 display (includes microphone) 534992-001
For use with 16-in Presario CQ-61 display (includes microphone and webcam) 534994-001
For use with 15.6-in Presario CQ-61 display (includes microphone and webcam) 534993-001
For use with 15.6-in Presario CQ-61 display (includes microphone) 534995-001
(2) Webcam module (webcam module cable included in Display Panel Cable Kit, 534077-001) 531202-001
(3) High Definition display panel (includes display panel and backlight cables)
For use only with 16-in display 531216-001
For use only with 15.6-in display 517842-001
(4) Display panel bracket (includes left and right brackets)
For use with 16-in display panels 530996-001
For use with 15.6-in display panels 530995-001
Display Panel Cable Kit with webcam cable (not illustrated) 534077-001
(5) Display Hinge Kit (includes left and right display hinges) 530993-001
(6) Wireless Antenna Kit (includes wireless antenna transceivers and cable)
(7) Microphone and caps lock cable (includes receiver and cable) 531203-001
(8) Display enclosure (includes logo)
For use only with HP G61 computer models 530990-001
For use only with Presario CQ61 computer models 530989-001
Display Rubber Kit (not illustrated, includes display bezel rubber screw covers) 530999-001
Display Screw Kit (not illustrated)
■ Phillips PM2.5x5.0 screw
■ Phillips PM2.0x3.0 screw
■ Phillips PM2.5x6.5 screw
531201-001
