Removal and replacement procedures
Maintenance and Service Guide 4–31
3. Turn the computer right-side up, with the front facing you.
4. Remove the Phillips PM2.5×6.0 screw that secures the top cover to the computer.
5. Lift the rear edge of the top cover 1 until the top cover disengages from the base enclosure.
6. Release the LIF connector 2 for the two TouchPad cables from the system board .
7. Remove the top cover 3.
✎
The TouchPad is glued to the top cover and is included with the top cover spare part.
Reverse this procedure to install the top cover.
