2. Look at the exposed edge of the SNMP module.
• If an LED is mounted near the button switch, the installed SNMP
module is the HP J2603B version; you can proceed with installing
the router module.
• If there is no LED there, the module is the HP J2603A version;
contact your HP dealer for information about obtaining the
HP J2603B version.
3. If you will not be installing the router module now, reinstall the cover
plate:
a. Insert the tabs on the bottom of the cover plate in the small slots
in the bottom of the Expansion Slot.
b. Close the cover plate, then tighten the two captured screws using
a Torx T-10 or flat-blade screwdriver. Be careful not to
overtighten them.
Button switch
If this LED is present,
the SNMP module is
the proper version
Figure 1-2. Checking SNMP Module
Installation
1. Check the Version of the SNMP Module.
1-6
