8. Using your fingers (or a nonmetallic tool), carefully lift up the
battery clip slightly, then slide the battery out of its holder.
Caution Replace the battery only with the same type.
9. Carefully insert the new battery—positive (+) side up—into the
battery holder.
10. Reassemble the the router module with the SNMP module, then rein-
stall them in the hub, as described in steps 6 – 12 on pages 1-13 – 1-15.
WARNING Dispose of the used battery properly. Do not attempt to recharge,
crush, or disassemble it; do not incinerate it or expose it to heat
above 100°C (212°F).
Figure 4-1. Removing Battery
Troubleshooting
Replacing the Battery
4-16
