Back-to-Back Test Cable—Minimum Pin-Outs
62-pin male 62-pin male
SDA 17 1 RDA
SDB 38 22 RDB
RDA 1 17 SDA
RDB 22 38 SDB
RSA 15 4 CSA
RSB 36 25 CSB
CSA 4 15 RSA
CSB 25 36 RSB
TRA 16 5 DMA
6 RRA
TRB 37 26 DMB
27 RRB
DMA 5 16 TRA
RRA 6
DMB 26 37 TRB
RRB 27
TTA 14 2 STA
3RTA
TTB 35 23 STB
24 RTB
STA 2 14 TTA
RTA 3
STB 23 35 TTB
RTB 35
GND 9 9 GND
10 10
30 30
32 32
shield shield
Note In the cable, each of the differential signal pairs (SDA and SDB, RDA
and RDB, and so on) must be twisted pairs of wire.
Cables and
Connectors
A
Cables and Connectors
Cable and Connector Pin-Outs
A-9
