6-36
Stack Management for the 3500, 3500yl, 6200yl and 6600 Switches
Configuring Stack Management
Using a Candidate CLI To Manually “Push” the Candidate Into a
Stack . Use this method if any of the following apply:
■ The Candidate’s Auto Join is set to Yes (and you do not want to enable
Auto Grab on the Commander) or the Candidate’s Auto Join is set to No.
■ Either you know the MAC address of the Commander for the stack into
which you want to insert the Candidate, or the Candidate has a valid IP
address and is operating in your network.
Syntax: stack join < mac-addr >
where: < mac-addr > is the MAC address of the Commander in
the destination stack.
Use Telnet (if the Candidate has an IP address valid for your network) or a
direct serial port connection to access the CLI for the Candidate switch. For
example, suppose that a Candidate named “North Sea” with Auto Join off and
a valid IP address of 10.28.227.104 is running on a network. You could Telnet
to the Candidate, use show stack all to determine the Commander’s MAC
address, and then “push” the Candidate into the desired stack.
Figure 6-31. Example of “Pushing” a Candidate Into a Stack
To verify that the Candidate successfully joined the stack, execute
show stack
all
again to view the stacking status.
HP Switch# telnet 10.28.227.104
HP Switch# show stack all
Stacking - Stacking Status (All)
Stack Name MAC Address System Name Status
--------------- ------------- ------------------------- ------------
Big_Waters 1cc1de-cfbc80 Big_Waters-0 Commander Up
000883-08f980 Big_Waters-1 Member Up
000883-08f234 Big_Waters-2 Member Up
Others: 0001e6-0421c0 North Sea Candidate
North Sea# config
North Sea(config)# 1cc1de-cfbc80
1. Telnet to the Candidate named “North Sea”.
2. Use show stack all to display the Commander’s
MAC address.
3. Set the Candidate CLI to Config mode.
4. Execute stack join with the
Commander’s MAC address to “push”
the Candidate into the stack.
MAC Address for
Stack Commander
