33
Specifications
Network Connectivity Speeds and Technologies
Table 1. Optional Network Connectivity, Speeds and Technologies
Transceiver Form-Factor and Connector
1
Speed Technology
Cabling
SFP ("mini-GBIC")
Connector
X2
Connector
SFP+
Connector
100 Mbps
100-FX Fiber (multimode) LC
100-BX Fiber (single mode) LC
1 Gbps
1000-T Copper (twisted-pair) RJ-45
1000-SX Fiber (multimode) LC
1000-LX Fiber (multimode or single mode) LC
1000-LH Fiber (single mode) LC
1000-BX Fiber (single mode) LC
10 Gbps
10-Gig CX4 Copper (twinaxial) CX4
10-Gig
Direct Attach
Copper (twinaxial) Not
Applicable
10-Gig SR
Fiber (multimode) SC
LC
10-Gig LRM Fiber (multimode) SC
LC
10-Gig LR Fiber (single mode) SC LC
10-Gig ER
Fiber (single mode) SC LC
1
For supported transceivers, visit www.hp.com/networking/support.
– In the first textbox, type J4858 (for 100-Mb and Gigabit information), or J8436 (for 10-Gigabit information).
– Select any of the products that display in the dropdown list.
– Select P
roduct support information. The
n click on Manuals and find the Transceiver Support Matrix.
For technical details of cabling and technologies see "Cabling and Technology Specifications" on page 36.
