Component Function
1 AC Power Connector Connects the AC power cord to the monitor.
2 Audio In (select models) Connects the audio cable to the monitor's internal speakers.
3 DVI Connects the DVI-D cable to the monitor.
4 VGA Connects the VGA cable to the monitor.
5 USB Upstream
Connector
Connects the USB hub cable to the monitor's USB hub
connector and to a host USB port/hub.
6 USB Downstream
Connectors (2)
Connects optional USB devices to the monitor (2 additional
downstream USB connectors are on the left side of the
monitor's front panel).
8 Chapter 3 Setting Up the Monitor
