HP L1750 User Manual

Adjusting the Monitor Settings
The monitor settings can be adjusted from the On-Screen Display (OSD) menu or from the HP Display
Assistant utility.
Using the On-Screen Display Menu
Use the On-Screen Display (OSD) to adjust the screen image based on your viewing preferences. To
access the OSD, do the following:
1. If the monitor is not already on, press the Power button to turn on the monitor.
2. To access the OSD Menu, press the Menu button on the monitor’s front panel.
3. To navigate through the OSD Menu, press the + (Plus) button on the monitor’s front panel to scroll
up, or the – (Minus)/Auto button to scroll in reverse.
4. To select an item from the OSD Menu, use the + or – buttons to scroll to and highlight your selection,
then press the Menu button to select that function.
5. Adjust the item using the + or – buttons on the front panel to adjust the scale.
6. After adjusting the function, select Save and Return, or Cancel if you don’t want to save the setting,
then select Exit from the Main Menu.
NOTE: If the buttons remain untouched for 10 seconds while displaying a menu, new adjustments will
be discarded and the settings will revert to previous settings and exit the menu.
Adjusting the Monitor Settings 25

HP L1750 Specifications

General

3D	No
Aspect ratio	16:9
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	50 - 77 Hz
Horizontal scan range	24 - 83 kHz
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	800:1
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
On/off switch	Yes
Power consumption (standby)	- W
USB Type-A downstream ports quantity	0
Tilt angle range	-5 - 35 °
Panel mounting interface	- mm
Product color	Silver
Country of origin	China
Cables included	AC
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	301 mm
Width (without stand)	377 mm
Height (without stand)	351 mm
Weight (without stand)	6800 g
