Removing the Monitor Pedestal Base
You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm,
or other mounting fixture.
CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and the
power and signal cables are both disconnected. If the monitor has a connected audio cable, disconnect
it.
1. Disconnect and remove the signal and power cables from the back of the monitor.
2. Lay the monitor face down on a flat surface.
3. Remove the screws on the back of the monitor that connect the monitor panel with the pedestal
base.
a. On the double-hinged base, there are four screws that connect the monitor panel to the
pedestal base.
Figure 3-17 Removing the Double-Hinged Pedestal Base
16 Chapter 3 Setting Up the Monitor
