HP L1940T User Manual

3
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then
follow the instructions below.
Unfolding the Monitor Base
The monitor is shipped with the base attached in a folded flat
position. To begin using the monitor, you must unfold the base
and place the monitor in an upright position.
Unfolding the Base
User Guide 3–1

HP L1940T Specifications

General

3D	No
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	5:4
Response time	8 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 83 kHz
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	700:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	140 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
On/off switch	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	2
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
AC input voltage	95 - 265 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	241 mm
Package width	508 mm
Package height	521 mm
Package weight	10200 g
Sustainability certificates	ENERGY STAR
Certification	CSA, CE, CISPR, FCC, ISO, TCO, VCCI, TUV, MPR-II
Country of origin	China

Weight and Dimensions

Depth (without stand)	273 mm
Width (without stand)	413 mm
Height (without stand)	362 mm
Weight (without stand)	8400 g
