Operating the Monitor
6. After adjusting the function, select Save and Return, or
Cancel if you don’t want to save the setting, then select Exit
from the Main Menu.
✎
If the buttons remain untouched for 10 seconds while displaying a
menu, the new adjustments will be saved when the OSD
automatically times out and exits the menu.
Using the On-Screen Display
There are two On-Screen Display menus available; one for basic
adjustments, and one for advanced adjustments.
To access the Basic OSD Menu, press the menu button on the
monitor's front panel.
Basic OSD Menu Levels
Menu Level 1 Menu Level 2
Brightness Adjustment Scale
Contrast Adjustment Scale
Auto Adjustment
Advanced Menu
Exit
To access the Advanced OSD Menu, press the menu button again,
or select Advanced Menu from the Basic OSD Menu.
✎
After selecting the Advanced Menu from the Basic Menu, the
Advanced Menu remains the default OSD on subsequent
power-ups of the monitor until the Basic Menu is selected or
Factory Reset is applied.
User Guide 4–7

HP L1940T Specifications

General

3D	No
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	5:4
Response time	8 ms
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 83 kHz
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	700:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	140 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
On/off switch	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	2
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
AC input voltage	95 - 265 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	241 mm
Package width	508 mm
Package height	521 mm
Package weight	10200 g
Sustainability certificates	ENERGY STAR
Certification	CSA, CE, CISPR, FCC, ISO, TCO, VCCI, TUV, MPR-II
Country of origin	China

Weight and Dimensions

Depth (without stand)	273 mm
Width (without stand)	413 mm
Height (without stand)	362 mm
Weight (without stand)	8400 g
