Table 7-7 Internal components (3 of 3)
Ref Description Part number Qty
1 Cover, gear, upper right RC1-7209-000CN 1
2 Cover, dust RC1-7118-000CN 1
3 Guide, cartridge, lower right RC1-7286-000CN 1
4 Guide, duplexer, left RC1-7379-000CN 1
5 Guide, duplexer, right RC1-7380-000CN 1
6 Flag, loop sensor RC1-7144-000CN 1
7 Spring, torsion RC1-7145-000CN 1
8 Spring, tension RU5-2563-000CN 2
9 Fan RK2-1089-000CN 1
10 High-voltage power supply (110V-127V) RM1-2957-000CN 1
10 High-voltage power supply (220V-240V) RM1-2958-000CN 1
11 Link, tag RC1-7289-000CN 1
12 Link, tag lock RC1-7294-000CN 2
13 Lever, shutter RC1-7451-000CN 1
14 Cover, shutter lever RC1-7452-000CN 1
15 Spring, compression RU5-2633-000CN 1
16 Spring, tension RU5-2651-000CN 1
17 Tag holder assembly RM1-2514-000CN 1
18 Holder, fan RC1-7434-000CN 1
19 Low-voltage power supply (110V-127V) RM1-2926-000CN 1
19 Low-voltage power supply (220V-240V) RM1-2951-000CN 1
20 Plate, cross member auxiliary RC1-7264-000CN 1
21 Laser/scanner assembly RM1-2555-000CN 1
ENWW Internal components 325
