2. If necessary, pull the guide (callout 1) and remove any visible paper (callout 2) from the bottom of
the delivery area.
3. If necessary, remove any visible paper from bottom side of the duplexing unit.
4. If you can not see any jammed paper, lift the duplexing unit using the tab on the side of the duplexing
unit.
5. If you can see the trailing edge of the paper, remove the paper from the product.
ENWW Clear jams 213
