HCI left tray
1. Open the left tray.
2. Lower the tray release lever (callout 1), and then remove the left tray (callout 2).
NOTE: When the tray is reinstalled, the release lever automatically returns to the locked
position.
Figure 1-359 Remove the HCI left tray
1
2
