Stapler/stacker left rear cover
Before proceeding, remove the following assemblies:
●
Stapler/stacker rear cover. See
Stapler/stacker rear cover on page 299.
Remove the stapler/stacker left rear cover
Release two tabs (callout 1), and then remove the cover.
Figure 1-410 Remove the stapler/stacker left rear cover
1
ENWW
Output devices
305
