Table 2-12 Manual sensor diagnostic tests (continued)
Sensor or switch Replacement Part number Description
PS3306 Tray 3 feed RM1-8876-000CN Paper pickup left assembly (right)
PS5 Top RM1-7922-000CN Registration sensor assembly
PS7 Fuser loop 1 CC522-67904 (110V)
CC522-67926 (220V)
Fuser
PS8 Fuser loop 2 CC522-67904 (110V)
CC522-67926 (220V)
Fuser
PS9 Fuser Pressure Release CE707-67904 Fuser drive assembly
PS6 Fuser Output CC522-67904 (110V)
CC522-67926 (220V)
Fuser
PS10 Output Bin Full CE707-67904 Fuser drive assembly
PS11 Developer Alienation CE708-67901 Main drive assembly
SW5 ITB Alienation CE708-67901 Main drive assembly
148 Chapter 2 Solve problems ENWW
