ENWW Installing the fax accessory 3
English
Installing/replacing the fax accessory in the
HP LaserJet 9040/9050mfp
This procedure provides information on how to install or replace the
fax card in the HP LaserJet 9040/9050mfp.
Note If you purchased the MFP with the fax accessory installed, you do not
need to perform this hardware installation; however, you will need to
connect the phone cord as described in steps 10 and 11 of this
procedure and you will also need to make the required configuration
settings. See “Making required fax settings” on page 21.
The fax accessory card is installed on the MFP formatter board which
must be removed to install the fax card. To install or to replace an
existing fax card, complete the following steps.
1 Unpack the fax card from the box. Do not remove the fax card
from its antistatic pouch.
2 Set the MFP’s power switch to off and disconnect the AC power
cord.
3 Locate the formatter board. The formatter board is attached to a
sheet-metal plate (1) located on the left side of the MFP towards
the back, see Figure 1-2.
Figure 1-2 HP LaserJet 9040/9050mfp formatter location
