2. Release the wire harnesses from the retainer (callout 1).
Figure 1-115 Remove the duplex-reverse drive assembly (2 of 4)
1
3. Remove three screws (callout 1).
Figure 1-116 Remove the duplex-reverse drive assembly (3 of 4)
1
