HP LaserJet Pro Color MFP M476dn

3. Remove the cables from the wire guides and then disconnect the plugs from the Driver PCA.
Figure 1-134 Unplugged wires have been removed from the wire guides and plugs from the Driver PCA
have been disconnected
4. Disconnect the large plug from the formatter board.
Figure 1-135 Disconnect the plug on the formatter board
98 Chapter 1 Removal and replacement ENWW
