Tray cassettes and optional Tray 3 assembly
1. Tray 2 and Tray 3 cassette: Pull the tray straight out of the product to remove it.
Figure 1-148 Remove the tray cassettes and optional Tray 3 assembly (1 of 2)
2. Optional Tray 3 assembly: Lift the product straight up from the assembly, and then set the product on
a sturdy, level surface.
CAUTION: Lift the product by using the right- and left-side hand-holds. Do not lift the product by
grasping the Tray 2 cassette, or the cavity created if the cassette is removed.
Figure 1-149 Remove the tray cassettes and optional Tray 3 assembly (2 of 2)
ENWW Removal and replacement procedures 105
