HP LaserJet Pro Color MFP M476dn - Page 84

2. Disconnect 11 connectors.
Figure 1-87 Remove the formatter PCA (1 of 2)
3. Remove four screws, and then remove the formatter PCA.
Figure 1-88 Remove the formatter PCA (2 of 2)
Fax PCA
1. Remove the right cover. See Right cover on page 25
66 Chapter 1 Removal and replacement ENWW
