Table 3-14 Alphabetical parts list (continued)
Description Part number Table and page
Cover, top RC3-4790-000 External panels and covers
on page 145
Delivery sensor PCB assembly RM2-7629-000 Internal assemblies (1 of 3)
on page 147
Duplexing door assembly RM1-9654-000 External panels and covers
on page 145
Duplexing frame assembly RM1-9655-000 Internal assemblies (2 of 3)
on page 149
Duplexing PCB assembly RM2-7608-000 Internal assemblies (3 of 3)
on page 151
Engine control PCB assembly, 110-127V RM2-7632-000 Internal assemblies (1 of 3)
on page 147
Engine control PCB assembly, 220-240V RM2-7633-000 Internal assemblies (1 of 3)
on page 147
Engine control PCB assembly, 220-240V, CH IN RM2-8080-000 Internal assemblies (1 of 3)
on page 147
Fan RK2-6694-000 Internal assemblies (3 of 3)
on page 151
Fixing assembly, 110-127V RM1-9891-000 Internal assemblies (1 of 3)
on page 147
Fixing assembly, 220-240V RM1-9892-000 Internal assemblies (1 of 3)
on page 147
Fixing film assembly, 110-127V RM1-9656-000 Internal assemblies (1 of 3)
on page 147
Fixing film assembly, 220-240V RM1-9657-000 Internal assemblies (1 of 3)
on page 147
Laser scanner assembly RM2-0426-000 Internal assemblies (3 of 3)
on page 151
Link, cartridge door RC2-9527-000 Internal assemblies (1 of 3)
on page 147
Link, cartridge door, CH IN RC2-9514-000 Internal assemblies (3 of 3)
on page 151
Link, pressure release RC2-9531-000 Internal assemblies (1 of 3)
on page 147
Motor PCB assembly RM2-7634-000 Internal assemblies (3 of 3)
on page 151
Motor, DC24V RM2-0418-000 Internal assemblies (3 of 3)
on page 151
Paper delivery tray assembly RM1-9649-000 External panels and covers
on page 145
Paper pick-up assembly RM2-6524-000 Internal assemblies (2 of 3)
on page 149
ENWW Alphabetical parts list 161
