HP LE1851w

18.5" LCD Color Monitor HP LE1851w
17
6.2 Electrical Block Diagram
6.2.1 Scalar Board
Scalar TSUM1PFR-LF
(Include ADC、OSD、MCU)
(U401)
FLASH MEMORY
PM25LV010A (U402)
D-Sub Connector
(CN101)
EPR_SDA
EPR SCL
Panel Interface
(CN403)
EEPROM
M24C02
(U104)
H sync
V sync
RGB
EEPROM
M24C04
(U403)
DB15_SDA,
DB15 SCL
