HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
35
7.4 Key Board
LED-G
GND
R004 30K 1/10W 5%
GND
ZD001
UDZ SNP5.6B
1 2
GND
R001 22K 1/10W 5%
POWER
R002 30K 1/10W 5%
ZD007
UDZ SNP5.6B
1 2
AMBERT
INPUT SELECT
ZD002
UDZSNP5.6B
1 2
ZD004
UDZSNP5.6B
1 2
SW003
SW
3 4
21
5
6
PLUS
MINUS
SW004
SW
3 4
21
5
6
GREEN
ADC1
CN001
CABLE
1
2
3
4
5
6
7
8
SW002
SW
3 4
21
5
6
LED001
2 4
1 3
Power
ZD005
UDZ SNP5.6B
1 2
GND GND
ADC2
ZD003
UDZSNP5.6B
1 2
<Doc> E
HP LP2275 Custom
22Wednesday , April 30, 2008
715G2953-E
<
称爹 >
02.Key Board
G2953-E-X-X-1-080429
OEM MOD EL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
LED-A
MENU
ZD006
UDZSNP5.6B
1 2
GND
SW001
SW
3 4
21
5
6
GND
SW005
SW
3 4
21
5
6
GND
R003 22K 1/10W 5%

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
