HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
59
A34G0674 EYA1B0130 REAR COVER22"
A34G0675 EY 1X0100 RUBBER CHANEL(L)
A34G0675 EY 2X0100 RUBBER CHANEL(R)
A85G0085101 USB SHILEDING
ADPC72412AA3 ADAPTER G2931-E-X-X-1-080527
040G 45762412B CBPC LABEL
IC950 056G 139 3A IC PC123Y22FZ0F
IC951 056G 139 3A IC PC123Y22FZ0F
IC955 056G 139 3A IC PC123Y22FZ0F
RV901 061G 46 17 VARISTOR 560V TNR14V561K
NR901 061G 58050 WT NTC 5 OHM 5A
C901 063G 10747410V 0.47UF 275VAC ARCO
C901 063G107K474 6S CAP X2 0.47UF K 275VAC
C911 063G213J105GFA MPF CAP
C912 063G213J105GFA MPF CAP
C929 065G 2M1033FE6921 CAP CER 10NF M 2KV Y5U
C913 065G 2M1033FE6921 CAP CER 10NF M 2KV Y5U
C904 065G305M1022BM 1000PF 250VAC
C905 065G305M1022BM 1000PF 250VAC
C908 065G305M1022BM 1000PF 250VAC
C909 065G305M1022BM 1000PF 250VAC
C909 065G305M1022BP Y2 1000PF M 250VAC Y5P
C908 065G305M1022BP Y2 1000PF M 250VAC Y5P
C905 065G305M1022BP Y2 1000PF M 250VAC Y5P
C904 065G305M1022BP Y2 1000PF M 250VAC Y5P
C903 065G306M1022BM Y1.CAP.001UF 250VAC MURATA
C982 065G306M1022BM Y1.CAP.001UF 250VAC MURATA
C906 065G306M1022BM Y1.CAP.001UF 250VAC MURATA
C903 065G306M1022BP 1000PF Y1.CAP
C982 065G306M1022BP 1000PF Y1.CAP
C906 065G306M1022BP 1000PF Y1.CAP
C914 067G215L10115N
EC CAP 105 度 100UF 450V
C964 067G215V102 6N EC 1000UF 35V KY35VB1000M-CC3 12.5*25MM
C965 067G215V102 6N EC 1000UF 35V KY35VB1000M-CC3 12.5*25MM
C955 067G215V102 6N EC 1000UF 35V KY35VB1000M-CC3 12.5*25MM
C956 067G215V102 6N EC 1000UF 35V KY35VB1000M-CC3 12.5*25MM
C957 067G215V471 3R LOW E.S.R 470UF +/-20% 16V
C966 067G215V471 6N
CAP 105℃ 470UF M 35V
FB902 071G 55 19 T FERRITE BEAD D9X3. 5X0.8
FB901 071G 5519R FERRITE BEAD

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
