HP LP2275w Service Manual

22" LCD Color Monitor HP LP2275w
66
C464 067G 2151014RT
EC 105℃ CAP 100UF M 25V
C410 067G 2151014RT
EC 105℃ CAP 100UF M 25V
C187 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C190 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C192 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C195 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C198 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C456 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C463 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C181 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C165 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C163 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C152 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C141 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C134 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C124 067G 2152207RT LOW E.S.R 22UF +/-20% 50V
C707 067G 2152214RT LOW E.S.R 220UF +/-20% 25V
C745 067G 2152214RT LOW E.S.R 220UF +/-20% 25V
C749 067G 2152214RT LOW E.S.R 220UF +/-20% 25V
C756 067G 4152214KT EC 220UF 25V M 8*12MM
C704 067G 4152214KT EC 220UF 25V M 8*12MM
C454 067G 4152214KT EC 220UF 25V M 8*12MM
U401 056G 562155 IC GM5862H-LF PQFP-256
U707 056G 563 7 IC AIC1084-33PMTR-R AIC
U701 056G 563 7 IC AIC1084-33PMTR-R AIC
U708 056G 563 57 AP1510SA
U706 056G 585 4 IC AIC1117-33PYTR-R AIC
U702 056G 585 5A IC AP1117E25L-13
U104 056G 586 15 IC GM69010H-BE QFP-160
U110 056G 587 4 IC MST30D1-LF PQFP-100
U109 056G 614 1 74HC4052D S016 PHLIPS
U405 056G 615 12 2 IC EM636165TS-5G 16M TSOPII-50 ETRON
U404 056G 615 12 2 IC EM636165TS-5G 16M TSOPII-50 ETRON
U101 056G 620 3 IC 74LV4053D SO-16
U704 056G 659 9 IC USB2514-AEZG QFN-36
U108 056G1133 32 IC M24C04-WMN6TP SO8
U102 056G1133 34 M24C02-WMN6TP
U103 056G1133 34 M24C02-WMN6TP
U106 056G1133 34 M24C02-WMN6TP
U705 056G1133 34 M24C02-WMN6TP

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
