3. Mount the Quick Release to a swing arm or other mounting fixture using the four screws

removed from the Quick Release in the previous step.

Figure 3-16 Installing the Quick Release

CAUTION The Quick Release can also be installed directly to a wall to mount the

monitor panel. It is designed to support a maximum of up to 24 lbs. (10.9 kg). If you are

mounting to a wall, HP recommends that you consult with a qualified engineering,

architectural, or construction professional to determine the appropriate type and quantity

of mounting fasteners required for your application and to ensure that the mounting

solution is properly installed to support applied loads.

4. Insert the monitor panel into the Quick Release, and then press down firmly on the monitor to

lock it in place. When the Quick Release locks, it will make a clicking sound.

Figure 3-17 Inserting the Monitor Panel into the Quick Release

16 Chapter 3 Setting Up the Monitor

Questions and Answers:

Need help?

Do you have a question about the HP LP2465 and is the answer not in the manual?

HP LP2465 Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:10
Response time	6 ms
Display diagonal	24 \
Separate H/V sync	Yes
Display resolution	1920 x 1200 pixels
Vertical scan range	48 - 85 Hz
Viewable size, vertical	326 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	520 mm
Display brightness (typical)	500 cd/m²
USB hub version	2.0
DVI-I ports quantity	2
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
Product color	Black, Silver
Country of origin	China
Pivot angle	0 - 90 °
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	75 W
Sustainability certificates	ENERGY STAR
