HP LSI 9212 4-Port SAS 6Gb/s RAID Card User Manual

PCI Bus 8-lane, 5GT/s PCI Express 2.0
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 1E and 10
PCI Data Burst Transfer
Rate
Half Duplex, x4 PCIe 2000 MB/s
Full Duplex, x8 PCIe 4000 MB/s
SAS Bandwidth Half Duplex Single lane - 600 MB/s
Wide Port (2 lanes) - 1200 MB/s
Wide Port (4 lanes) - 2400 MB/s
Full Duplex Single SAS Lane - 1200 MB/s
Wide Port (2 lanes) -2400 MB/s
Wide Port (4 lanes) - 4800 MB/s
PCI Card Type 3.3V Add-in card
PCI Voltage 12 V ± 10%
PCI Power 13.5 Watts
Bracket Full height and Low-profile
Certification Level PCI-Express 2.0
IO Bus 1x4 6Gb/s SAS ports
SAS Processor LSISAS2008
Internal Connectors Four x1 SATA
External Connectors None
Maximum Number of SCSI
Devices
256
LED Indicators Internal
Activity/Fault per x4 port - Heartbeat
Temperature Operating 0° to 55° C
Storage -45° to +105° C
Relative Humidity Operating 5 to 90% non-condensing
Storage 5 to 90% non-condensing
MTBF >2,000,000 hours
Compliances EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04);Europe (EN55022/EN55024);
Australia/New Zealand (AS/NZS 3548); Safety: EN60950
Operating System Support Microsoft® Windows® XP Professional, XP Professional 64-bit Genuine Windows Vista® Business 32-bit and
64-bit Genuine Windows 7 Professional 32-bit and 64-bit. Linux SLED and RHEL.
Kit Contents Controller card, driver CD, LED cables, user documentation and warranty card.
© Copyright 2011 Hewlett-Packard Development Company, L.P.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein. The information contained herein is subject to change without notice.
QuickSpecs
LSI 9212 4-Port SAS 6Gb/s RAID Card
Technical Specifications
DA - 13943 North America — Version 5 — June 1, 2011 Page 3
