Reinstallation tip When reinstalling the scanner spring assembly, position the spring at each end so that
the short wire rests in the notch on the bottom of the scan drive chassis.
Figure 1-129 Reinstall the scanner spring assembly
90 Chapter 1 Removal and replacement ENWW
