5. Disconnect one FFC (callout 1) from the control panel.
CAUTION: Do not bend or fold the flat flexible cables (FFCs) during removal or installation. Also, do
not straighten pre-folds in the FFCs.
Figure 1-42 Remove the control panel (5 of 5)
1
