HP M176 - Page 61

2. Carefully remove the FFC from the cable guides (callout 1).
NOTE: The FFC guide might look slightly different, but the procedure is the same.
Figure 1-54 Remove the wireless PCA for the M177 model (2 of 3)
1
3. Remove one screw (callout 1), and then remove the wireless PCA and the FFC guide (callout 2).
NOTE: The wireless PCA holder might look slightly different, but the procedure is the same.
Figure 1-55 Remove the wireless PCA for the M177 model (3 of 3)
2
1
ENWW Removal and replacement procedures 43
