2. Remove three black screws (callout 1) and the scanner cover (callout 2).
Figure 1-61 Remove the control panel FFC (2 of 5)
1
2
3. Remove one tapping screw (callout 1) and the spring holder (callout 2).
Figure 1-62 Remove the control panel FFC (3 of 5)
1
2
ENWW Removal and replacement procedures 47
