4. Release one tab (callout 1) and remove the cable cover (callout 2).
Figure 1-76 Remove the fuser delivery assembly (4 of 9)
2
1
5. Disconnect one connector (callout 1).
Figure 1-77 Remove the fuser delivery assembly (5 of 9)
1
56 Chapter 1 Removal and replacement ENWW
