HP M27 - How to Order Parts

10
How to order parts
The HP authorized repair center can purchase the adaptor from HP.
Power board
Description
HP spare part number
Manufacturer part number
M24 Webcam
N12399-001
PLPCLE454GFBZ
M27 Webcam
N12400-001
PLPCLH471GFA1
N12400-002
PLPCLH651BFB2
Capacitors and connectors are available for purchase from the following EU distributors:
 Farnell: Farnell UK - Electronic Components Distributor
 RS Component: Capacitors | RS Components (rs-online.com)
 DK : https://www.digikey.com/
Connectors by manufacturer
Component
description
Location identifier
Component distributor
Distributer part
number
CONN PHONE JACK
CN601
DK
839-54-00175TR-ND
839-54-00175CT-ND
839-54-00175DKR-ND
（54-00175）
HDMI
CN501
DK
1-1747981-1
DP
CN502
DK
670-2430-ND/JAE
USB 3.0 TYPE A
CN1101,CN1102
DK
732-3146-2-ND
732-3146-1-ND /WE
USB Type-C
CN5102
DK
670-2846-2-ND
670-2846-1-ND
670-2846-6-ND/JAE
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need modifications to
20
Cover Webcam
1
21
lens Webcam
1
S1
SCREW M3 X4
14
S2
SCREW Q4 X4
5
S3
SCREW M3 X6
6
S4
SCREW M4 X6
1
S5
SCREW M4 X10
4
