HP M27 - Power Board Removal

16
Remove the middle
frame
Remove the
screws by the
screwdriver
PANEL
Power board
The power board part number is PLPCLH471GFA1 .
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 12.
Remove the power board:
1) The HP M27 power board connector position is as follows:
