HP M27 User Manual

22
Sleep mode.
Video card is incompatible.
Open the OSD menu and
select the Input Control menu.
Set Auto-Switch Input to Off
and manually select the input
Image appears
blurred, indistinct,
or too dark.
Brightness is too low.
Open the OSD menu and
select Brightness to adjust the
brightness scale as needed.
Check Video Cable
is displayed on
screen.
Monitor video cable is disconnected.
Connect the appropriate video
signal cable between the
computer and monitor. Be
sure that the computer power
is off while you connect the
video cable.
Input Signal Out
of Range is
displayed on
screen.
Video resolution and/or refresh rate are set higher
than what the monitor supports.
Change the settings to a
supported setting.
The monitor is off,
but it did not seem
to enter into Sleep
mode.
The monitor’s power saving control is disabled.
Open the OSD menu and
select Power Control > Auto-
Sleep Mode and set auto-sleep
to On.
On-Screen Menus
are Locked is
displayed.
The monitor’s OSD lock function is enabled.
Press and hold the Menu
button on the front bezel to
10 seconds to disable the
OSD lockout function.
Power Button is
Locked is
Displayed
The monitor’s power button is locked.
Press and hold the power
button for 10 seconds to
disable the power button lock
function.

HP M27 Specifications

General

Color gamut	99 %
Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Pixel density	82 ppi
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display diagonal (metric)	68.58 cm
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	30 - 85 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	130 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Operating temperature (T-T)	5 - 35 °C
Package depth	211.4 mm
Package height	544 mm
Package weight	11300 g
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
Certification	Argentina S-Mark; BIS; CB; CCC; CE; CEL; CEL Grade 1; C-Tick; cTUVus; ENERGY STAR®; EPA; EUP Lot-5; EUP Lot-6; FCC; GS Mark; ICES; ISO 9241-307; KC/KCC; NOM; NOM (Mexico); RCM; UL/CSA-NTRL/ETL-NRTL Mark; VCCI; WEEE; EUP Lot-26; California Energy Commission (CEC); South Africa Energy; eStandby; Mexico LASE form; ICE; KES; PSE EAC; India BIS
Product color	Black, Silver
Country of origin	China
Market positioning	Home
Megapixel	5 MP
RMS rated power	4 W
Number of speakers	2
Sustainability certificates	ENERGY STAR
Depth	48.2 mm
Height	413 mm

Weight and Dimensions

Depth (with stand)	54.4 mm
Width (with stand)	61.2 mm
Height (with stand)	21.14 mm
Weight (with stand)	7300 g
Depth (without stand)	4.82 mm
Width (without stand)	612 mm
Height (without stand)	41.3 mm
