Removal and replacement procedures
NOTE: The following assemblies are Customer Self Repair (CSR) components. Go to Covers on page 106 or
Main assemblies on page 123 for information about removing service assemblies.
Print cartridges
When a print cartridge approaches the end of its estimated useful life, the control panel displays a message
recommending that you order a replacement. The product can continue to print using the current print
cartridge until the control panel displays a message instructing you to replace the cartridge, unless you have
selected the option to override the message by using the Supply Settings menu.
NOTE: Cartridge life remaining is used to determine if a supply is near or at estimated end of life. Cartridge
life remaining is approximate only, and varies depending on types of documents printed and other factors.
The product uses four colors and has a different print cartridge for each color: black (K), magenta (M), cyan
(C), and yellow (Y).
You can replace a print cartridge when the print quality is no longer acceptable. The control-panel message
also indicates the color of the cartridge that has reached the end of its estimated useful life. Replacement
instructions are provided on the label on the print cartridge.
CAUTION: If toner gets on clothing, wipe it off with a dry cloth and wash the clothes in cold water. Hot water
sets toner into fabric.
NOTE: Information about recycling used print cartridges is contained in the print-cartridge box.
Replace print cartridges
1. Open the front door. Make sure that the door is completely open.
2. Grasp the handle of the used print cartridge and pull out to remove.
ENWW Removal and replacement procedures 85
