HP M750 series

1. Release one tab (callout 1), and then release one connector (callout 2).
Figure 2-24 Remove the encrypted HDD (1 of 2)
1
2
2. Remove the encrypted HDD.
Figure 2-25 Remove the encrypted HDD (2 of 2)
ENWW Removal and replacement procedures 103
