HP M750 series

1 x 500 left cover
1. Take the cassette out of the feeder, release one tab (callout 1), and then remove the lever (callout 2).
Figure 2-174 Remove the 1 x 500 left cover (1 of 2)
1
2
2. Remove one screw (callout 1), release four tabs from the inside (see the tip that follows this step), and
then remove the left cover (callout 2).
Figure 2-175 Remove the 1 x 500 left cover (2 of 2)
1
2
212 Chapter 2 Removal and replacement ENWW
