1 x 500 right-front cover
1. Take the cassette out of the feeder, and then open the right door.
2. Remove one screw (callout 1), and then remove the right-front cover (callout 2).
Figure 2-176 Remove the 1 x 500 right-front cover
2
1
214 Chapter 2 Removal and replacement ENWW
