Figure 3-30 Product connections (3 of 6)
J1001
J557
J558
J559
J560
1
2
3
4
5
6
Item Description
1 High-voltage power supply imaging (developing) PCA
2 High-voltage power supply 1st transfer PCA
3 Driver PCA
4 DC controller PCA
5 High-voltage power supply 2nd transfer PCA
6 Toner remaining detect PCA
316 Chapter 3 Solve problems ENWW
