Table 4-5 External covers, panels, and doors
Ref Description Part number Qty
1 Cover, top RM1-7148-000CN 1
2 Door, toner collection unit access RC2-7034-000CN 1
3 Cable, USB RK2-2901-000CN 1
4 Cover, rear RM1-7147-000CN 1
5 Cover, right rear RM1-7142-000CN 1
6 Cover, handle, lower-right, rear RC2-6626-000CN 1
7 Cover, handle, lower-right, front RC2-6627-000CN 1
8 Cover, right front assembly (includes control panel) RM1-7144-000CN 1
9 Cover, front assembly CE707-67902 1
10 Cover, handle, lower-left RC2-6625-000CN 2
11 Cover, left assembly RM1-7143-000CN 1
ENWW External covers, panels, and doors 549
